Laverda 225 REV, 255 REV, 256 REV Combine Harvester Workshop Manual
Digital download. Your access link is provided after payment on the order confirmation page and/or by email. No physical item is shipped.
Laverda 225 REV, 255 REV, 256 REV Combine Harvester Workshop Manual – digital workshop manual (411 pages, language: English, format: PDF). The file is available to download after purchase; nothing is shipped.
Before ordering, compare the models in the title and the serial number range with the identification plate on your machine. Not sure this is the right manual? Contact us with your model and serial number.
Original Laverda workshop manual (print no. 327163010, 2004) for the REV series combine harvesters with IVECO NEF engines. It covers removal, installation, adjustment and testing of every main group of the machine – from the engine, transmission and hydrostatic drive to the threshing, separation and cleaning units – with exploded views, hydraulic circuit diagrams and complete electrical wiring diagrams.
Models covered: Laverda 225 REV, 255 REV, 256 REV
Highlights
- IVECO NEF engine data, identification code and service procedure
- Hydraulic circuit general diagram and component location
- Electrical system: wiring diagrams, fuses and relays, Agritronic electronics
- Header, reel, threshing drum and concave adjustments
- Capacities, lubricants and tightening torques
Contents
- 00 General information (capacities, tyres, belt tension, rotation speeds)
- 10 Engine (specifications, service, self-diagnosis)
- 14 Live PTO
- 21 Transmission
- 25 Front drive axle
- 29 Hydrostatic transmission
- 33 Brakes and controls
- 35 Hydraulic systems
- 41 Steering
- 44 Axles and wheels
- 50 Cab conditioning / climate control
- 55 Electrical systems
- 58 Attachments / headers
- 60 Product feeding
- 66 Threshing
- 72 Separation
- 73 Straw chopper
- 74 Cleaning
- 80 Grain storage
See also: Update appendices 327163011 and 327163012 (also available in our shop).
DETAILS
Size: 63.9 MB
Format: PDF
Language: English
Brand: Laverda
number of pages:411
Type of document: Workshop manual
Laverda ref. no.: 327163010
Contents vary by manual. Check the product description for the models covered, document sections, language and file format. If you need a specific diagram or procedure, contact us before purchasing.
